110*200*53mm Excavator Swing Bearing 22222 CA/CC/W33

Product Details

Place of Origin: China

Brand Name: SFT

Model Number: 22222 CA/CC/W33

Payment & Shipping Terms

Minimum Order Quantity: negotiable

Price: negotiable

Packaging Details: carton,pallet

Delivery Time: 20-45DAYS

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 50000PCS/MONTH

Get Best Price
Highlight:

110*200*53mm Excavator Swing Bearing

,

22222 Excavator Swing Bearing

,

110*200*53mm excavator swing bearing replacement

Application:
Concrete Mixer Truck
Hardness:
HRC60-65
Cage Material:
Copper Cage Steel Cage
Lubrication:
Standard Lubrication
Number Of Row:
Single Row
Seals Type:
Open
Application:
Concrete Mixer Truck
Hardness:
HRC60-65
Cage Material:
Copper Cage Steel Cage
Lubrication:
Standard Lubrication
Number Of Row:
Single Row
Seals Type:
Open
110*200*53mm Excavator Swing Bearing 22222 CA/CC/W33

22222 CA/CC/W33 Spherical Roller Bearing





Spherical roller bearings with two rollers, mainly bear radial load, but also can withstand axial load in either direction. A high radial load capacity, especially suitable for heavy loads or vibration, but can not bear the pure axial load. This kind of bearing outer ring raceway is spherical shape, so the good performance of its self-aligning, can compensate concentricity error.


There are two symmetrical spherical roller, there is a common spherical outer ring raceway, the bearing inner ring with two axis tilt

Angle of raceway, aligning with good performance, when the axis force bent or install a different heart is still bearing the normal use, transfer concentric with the bearing size range varies, generally aligning allowed 1 to 2.5 degree angle load bearing capacity of the larger type, in addition to radial loads but also under way outside the role of bearing axial load, with good impact resistance, in general, self-aligning roller bearings allowed working speed than the low.

C(J),EC(J).CA,ECA,CAF,CAFA, and so on.

1.CA: Integral brass cage, double row symmetrical rollers,inner ring ride

2.MA: Integral brass cage, double row symmetrical rollers ,outer ring ride

3.MB: Two piece brass cage,double row asymmetrical rollers, inner ring ride

4.CC: Two piece steel cage, double row symmetrical rollers,inner ring ride

5.CTN1: Double row symmetrical rollers ,nylon cage

6.K: Tapered bore bearing, the taper is 1:12

7.K30: Tapered bore bearing,the taper is 1:3



Self-aligning Spherical roller bearing Application:

1. printing presses, paper mills or coaters in high precision execution

2. very arduous operating conditions, e. g.continuous casters

3. high temperature applications

4. mounting with loose fit on roll necks

5. railway vehicles



22200 Series

Model

 d mm

D mm

H mm

W kg

22224

120

215

58

8.7

22226

130

230

64

11

22228

140

250

68

14

22230CA

150

270

73

18

22232CA

160

290

80

22.5

22234CA

170

310

86

28.5

22236CA

180

320

86

29.5

22238CA

190

340

92

38.6

22240CA

200

360

98

43.5

22244CA

220

400

108

60.5

22248CA

240

440

120

83

22252CA

260

480

130

110

22256CA

280

500

130

115

22260CA

300

540

140

145

22264CA

320

580

150

175

22272CA

360

650

170

255











22205

25

52

18

0.17

22206

30

62

20

0.29

22207

35

72

23

0.46

22208

40

80

23

0.53

22209

45

85

23

0.59

22210

50

90

23

0.63

22211

55

100

25

0.84

22212

60

110

28

1.15

22213

65

120

31

1.55

22214

70

125

31

1.55

22215

75

130

31

1.70

22216

80

140

33

2.10

22217

85

150

36

2.66

22218

90

160

40

3.40

22219

95

170

43

4.15

22220

100

180

46

4.90

22222

110

200

53

7.00

22224

120

215

58

8.7

22226

130

230

64

11

22228

140

250

68

14
