6 Inch Spherical Plain Shaft Bearing GEZ152ES

Product Details

Place of Origin: China

Brand Name: SFT

Model Number: GEZ152ES

Payment & Shipping Terms

Minimum Order Quantity: negotiable

Price: negotiable

Packaging Details: carton,pallet

Delivery Time: 20-45DAYS

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 50000PCS/MONTH

Get Best Price
Highlight:

6 Inch Spherical Plain Shaft Bearing

,

GEZ152ES Spherical Plain Shaft Bearing

,

GEZ152ES

OD:
1.0625inch
ID:
0.625inch
Material:
Steel/Steel And Steel/PTFE Fabric Material
Type:
Plain Shaft Bearing
Application:
Industry,engineering
Sliding Contact Surfaces:
Steel / PTEF Composite
OD:
1.0625inch
ID:
0.625inch
Material:
Steel/Steel And Steel/PTFE Fabric Material
Type:
Plain Shaft Bearing
Application:
Industry,engineering
Sliding Contact Surfaces:
Steel / PTEF Composite
6 Inch Spherical Plain Shaft Bearing GEZ152ES

6 Inch Spherical Plain Shaft Bearing Manufacturer GEZ152ES



Product Description of Spherical Plain Bearing:



Radial Spherical plain bearings are design to cater to all heavy loading equipments.

Plain bearings are able to cater to various sliding contact surfaces;

Steel/PTFE composite material and Steel/PTFE fabric material.

Range of production range from ID15mm to ID250mm.



Feature

1, Material: the inner and outer rings are bearing steel(GCr15).
2, Heat Treatment: the inner and outer rings are quenched and phosphating.
3, Structure: There are oil groove and oil hole in the inner and outer ring.The outer ring has an axial slot.
4, The sliding surface coated with MoS2 powder lubricant.
5, Performance Characteristic: It has the advantages of abrasion resistance, corrosion resistance,and self aligning . It applies to the machine which requires heavy radial load and axial load in a small-range direction.

Material
Ball: Chrome Steel GCr15, heat treated, phosohate-treated
Outer ring: Chrome Steel GCr15, heat treated, phosohate-treated



GEZ...ES/GEZ...ES 2RS Inch Size Spherical Bearing

6 Inch Spherical Plain Shaft Bearing Manufacturer GEZ152ES

  Part number Bore diameter Outer diameter Ball width Race width Static radial loads Dynamic radial loads Weight
  Without seals With seals Inch Inch Inch Inch LBS LBS LBS
1 GEZ12ES - 0.5 0.875 0.437 0.375 9.337 3,156 0.044
2 GEZ15ES - 0.625 1.0625 0.547 0.469 14.732 4864 0.077
3 GEZ19ES GEZ19ES-2RS 0.75 1.25 0.656 0.562 20.927 7089 0.121
4 GEZ22ES GEZ22ES-2RS 0.875 1.4375 0.765 0.656 28.573 9565 0.187
5 GEZ25ES GEZ25ES-2RS 1 1.625 0.875 0.75 37.359 12605 0.265
6 GEZ31ES GEZ31ES-2RS 1.25 2 1.093 0.937 58.507 19468 0.507
7 GEZ34ES GEZ34ES-2RS 1.375 2.1875 1.187 1.031 69.756 23404 0.772
8 GEZ38ES GEZ38ES-2RS 1.5 2.4375 1.312 1.125 84.379 28129 0.926
9 GEZ44ES GEZ44ES-2RS 1.75 2.8125 1.531 1.312 114.752 38255 1.41
10 GEZ50ES GEZ50ES-2RS 2 3.1875 1.75 1.5 150.754 50508 2.05
11 GEZ57ES GEZ57ES-2RS 2.25 3.5625 1.969 1.687 191.251 63002 2.87
12 GEZ63ES GEZ63ES-2RS 2.5 3.9375 2.187 1.875 234.007 77629 4.08
13 GEZ69ES GEZ69ES-2RS 2.75 4.375 2.406 2.062 285.752 95628 5.29
14 GEZ76ES GEZ76ES-2RS 3 4.75 2.625 2.25 337.506 112505 6.84
15 GEZ82ES GEZ82ES-2RS 3.25 5.125 2.844 2.437 396.009 131626 8.38
16 GEZ88ES GEZ88ES-2RS 3.5 5.5 3.062 2.625 459.001 153003 10.58
17 GEZ95ES GEZ95ES-2RS 3.75 5.875 3.281 2.812 531.004 175507 12.79
18 GEZ101ES GEZ101ES-2RS 4 6.25 3.5 3 596.256 202508 15.44
19 GEZ114ES GEZ114ES-2RS 4.5 7 3.937 3.375 765.002 252006 21.61
20 GEZ120ES GEZ120ES-2RS 4.75 7.375 4.156 3.562 843.754 281254 25.36
21 GEZ127ES GEZ127ES-2RS 5 7.75 4.375 3.75 933.755 315009 29.76
22 GEZ152ES GEZ152ES-2RS 6 8.75 4.75 4.125 1170.002 389257 38.59





Design and application

GEG..E: As Series GE..E, but with wider inner ring and larger outside diameter, for bearing arrangement where a larger angle of tilt is needed, which is suitable for larger loads mechanism.

GEG..ES: As series GE..ES, but wider inner ring and larger diameter, for bearing arrangement where a larger angle if tilt is needed which is suitable for larger loads mechanism.

GEG..ES 2RS: As series GE..ES 2RS, but wider inner ring and larger diameter, for bearing arrangement where a larger angle if tilt is needed which is suitable for larger loads mechanism, or a hole in the rod end. It has characteristics of large load capacity, easy mounting and dismounting and mechanism simplification.
