Product Details
Place of Origin: China
Brand Name: SFT
Model Number: GEG12ES
Payment & Shipping Terms
Minimum Order Quantity: negotiable
Price: negotiable
Packaging Details: carton,pallet
Delivery Time: 20-45DAYS
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 50000PCS/MONTH
OD: |
22mm |
ID: |
12mm |
Material: |
Steel/Steel And Steel/PTFE Fabric Material |
Type: |
Geew Spherical Plain Bearing |
Application: |
Industry,engineering |
Sliding Contact Surfaces: |
Steel / PTEF Composite |
OD: |
22mm |
ID: |
12mm |
Material: |
Steel/Steel And Steel/PTFE Fabric Material |
Type: |
Geew Spherical Plain Bearing |
Application: |
Industry,engineering |
Sliding Contact Surfaces: |
Steel / PTEF Composite |
GEG12ES Maintenance Free Radial Spherical Plain Bearing Price
Product Description of Spherical Plain Bearing:
Radial Spherical plain bearings are design to cater to all heavy loading equipments.
Plain bearings are able to cater to various sliding contact surfaces;
Steel/PTFE composite material and Steel/PTFE fabric material.
Range of production range from ID15mm to ID250mm.
Features of Metric Size Spherical plain bearing
• Extended Inner ring eliminating need for locating spacers.
• Sliding surface: Steel on Steel - MoS2 treated.
• Single fracture design.
• Relubricatable through annular grooves and oil holes in inner & outer rings (ES- Suffix)
| SPECIFICATION | |
| Model | GEEW12ES |
| Material | Stainless Steel / PTFE |
| Inner diameter | 12mm |
| Outer diameter | 22mm |
| ball width | 12mm |
| Model Available | GE, GEES2RS, GAC, GEC, GEG, GEZ, GEEM, GET, ...... |
| Application | Agricultural machinery, Shock absorber, etc |
| Package | Tube, carton box, wooden box, pallet |
| Delivery time | 1 day for sample, 3-5 day for medium order, 10-20 day for big order quantity |
| OEM | Accept |
| Payment terms | TT, L.C, D/A, D/P, Western Union, Paypal |
GEG...ES/GEEW...ES Metric Size Spherical Plain Bearing
| Part # | Ref # | Dimensions (mm) | Load Ratings kN | Weight LBS | |||||||||
| d | D | B | C | d1 | dk | rs | r1s | a | Dynamic | Static | |||
| max | min | min | « | ||||||||||
| GEG12ES | GEEW12ES | 12 | 22 | 12 | 7 | 15.5 | 18 | 0.3 | 0.3 | 4 | 10 | 53 | 0.022 |
| GEG15ES | GEEW15ES | 15 | 26 | 15 | 9 | 18.5 | 22 | 0.3 | 0.3 | 5 | 16 | 84 | 0.031 |
| GEG16ES | GEEW16ES | 16 | 28 | 16 | 9 | 20 | 23 | 0.3 | 0.3 | 4 | 17 | 85 | 0.035 |
| GEG17ES | GEEW17ES | 17 | 30 | 17 | 10 | 21 | 25 | 0.3 | 0.3 | 7 | 21 | 106 | 0.044 |
| GEG20ES | GEEW20ES | 20 | 35 | 20 | 12 | 25 | 29 | 0.3 | 0.3 | 4 | 30 | 146 | 0.071 |
| GEG25ES | GEEW25ES | 25 | 42 | 25 | 16 | 30.5 | 35.5 | 0.6 | 0.6 | 4 | 48 | 240 | 0.131 |
| GEG30ES | GEEW30ES | 30 | 47 | 30 | 18 | 34 | 40.7 | 0.6 | 0.6 | 4 | 62 | 310 | 0.168 |
| GEG32ES | GEEW32ES | 32 | 52 | 32 | 18 | 37 | 44 | 0.6 | 1 | 4 | 65 | 328 | 0.182 |
| GEG35ES | GEEW35ES | 35 | 55 | 35 | 20 | 40 | 47 | 0.6 | 1 | 4 | 79 | 399 | 0.253 |
| GEG40ES | GEEW40ES | 40 | 62 | 40 | 22 | 46 | 53 | 0.6 | 1 | 4 | 99 | 495 | 0.338 |
| GEG45ES | GEEW45ES | 45 | 68 | 45 | 25 | 52 | 60 | 0.6 | 1 | 4 | 127 | 637 | 0.481 |
| GEG50ES | GEEW50ES | 50 | 75 | 50 | 28 | 57 | 66 | 0.6 | 1 | 4 | 156 | 780 | 0.558 |
| GEG60ES | GEEW60ES | 60 | 90 | 60 | 36 | 68 | 80 | 1 | 1 | 4 | 245 | 1220 | 1.15 |
| GEG63ES | GEEW63ES | 63 | 95 | 63 | 36 | 71.5 | 83 | 1 | 1 | 4 | 253 | 1260 | 1.25 |
| GEG70ES | GEEW70ES | 70 | 105 | 70 | 40 | 78 | 92 | 1 | 1 | 4 | 313 | 1560 | 1.71 |
| GEG80ES | GEEW80ES | 80 | 120 | 80 | 45 | 91 | 105 | 1 | 1 | 4 | 400 | 2000 | 2.39 |
| GEG90ES | GEEW90ES | 90 | 130 | 90 | 50 | 99 | 115 | 1 | 1 | 4 | 488 | 2440 | 3.21 |
| GEG100ES | GEEW100ES | 100 | 150 | 100 | 55 | 113 | 130 | 1 | 1 | 4 | 607 | 3030 | 4.79 |
| GEG110ES | GEEW110ES | 110 | 160 | 110 | 55 | 124 | 140 | 1 | 1 | 4 | 654 | 3270 | 5.78 |
| GEG125ES | GEEW125ES | 125 | 180 | 125 | 70 | 138 | 160 | 1 | 1 | 4 | 950 | 4750 | 8.49 |
| GEG160ES | GEEW160ES | 160 | 230 | 160 | 80 | 177 | 200 | 1 | 1 | 4 | 1360 | 6800 | 16.5 |
| GEG200ES | GEEW200ES | 200 | 290 | 200 | 100 | 221 | 250 | 1.1 | 1.1 | 4 | 2120 | 10600 | 32.1 |
| GEG250ES | GEEW250ES | 250 | 400 | 250 | 120 | 317 | 350 | 1.1 | 1.1 | 4 | 3750 | 17800 | 99.1 |
| GEG320ES | GEEW320ES | 320 | 520 | 320 | 160 | 405 | 450 | 1.1 | 1.1 | 4 | 6200 | 30500 | 225 |
Design and application
GEG..E: As Series GE..E, but with wider inner ring and larger outside diameter, for bearing arrangement where a larger angle of tilt is needed, which is suitable for larger loads mechanism.
GEG..ES: As series GE..ES, but wider inner ring and larger diameter, for bearing arrangement where a larger angle if tilt is needed which is suitable for larger loads mechanism.
GEG..ES 2RS: As series GE..ES 2RS, but wider inner ring and larger diameter, for bearing arrangement where a larger angle if tilt is needed which is suitable for larger loads mechanism, or a hole in the rod end. It has characteristics of large load capacity, easy mounting and dismounting and mechanism simplification.
