Introduction
Joint bearing is a kind of special structure of sliding bearing. It is simple in structure than the rolling bearing, which is mainly composed of a spherical inner ring and a spherical outer ring, can bear larger load, according to the different types and structures, can be combined load to bear radial load, axial load and radial, axial exist at the same time.
Feature
High-grade carbon steel, corrosion protection,high hardness,rustless.
Professional manufacturing process.
Main tenance-free rod ends wite female thread,it is made up of a maintenance-free
spherical-plain radial bearing and rod body.
Right hand thread.
No maintenance required.
Inserts are in two half bronze rings.
Metal to Metal Support for Heavy Shock Loads.
Inner ball ring ,bearing steel ,polish ,hard- chromed plated.
Application
It is widely used in the industry of engineering hydraulic oil cylinder, metal forming machine, engineering machinery, automation equipment, auto damper, Water Conservancy Machine and so on.
it is generally used in low speed of swing motion, the angular motion, can bear larger load, can bear radial load, axial load or the joint of the radial, axial load.
| Bearing NO |
Diamensions(mm) |
Load rating |
a |
Weight(kg) |
| C1 |
d |
B |
dk |
d2 max |
G6h |
h |
L1 MIN |
L2MAX |
R15 MIN |
a |
Dynamic |
Static |
| SA5T/K |
6 |
5 |
8 |
11.11 |
18 |
M5*0.8 |
33 |
19 |
42 |
0.3 |
13 |
5.7 |
6.0 |
13 |
0.013 |
| SA6T/K |
6.75 |
6 |
9 |
12.7 |
20 |
M6*1 |
36 |
21 |
46 |
0.3 |
13 |
7.2 |
7.65 |
13 |
0.02 |
| SA8T/K |
9 |
8 |
12 |
15.875 |
24 |
M8*1.25 |
42 |
25 |
54 |
0.3 |
14 |
11.6 |
12.9 |
14 |
0.038 |
| SA10T/K |
10.5 |
10 |
14 |
19.05 |
28 |
M10*1.5 |
48 |
28 |
62 |
0.3 |
13 |
14.5 |
18 |
14 |
0.055 |
| SA12T/K |
12 |
12 |
16 |
22.225 |
32 |
M12*1.75 |
54 |
32 |
70 |
0.3 |
13 |
17 |
24 |
13 |
0.85 |
| SA14T/K |
13.5 |
14 |
19 |
25.4 |
36 |
M14*2 |
60 |
36 |
78 |
0.3 |
16 |
24 |
31 |
16 |
0.14 |
| SA16T/K |
15 |
16 |
21 |
28.575 |
42 |
M16*2 |
66 |
37 |
87 |
0.3 |
15 |
28.5 |
39 |
15 |
0.21 |
| SA18T/K |
16.5 |
18 |
23 |
31.75 |
44 |
M18*1.5 |
72 |
41 |
94 |
0.3 |
15 |
42.5 |
47.5 |
15 |
0.29 |
| SA20T/K |
18 |
20 |
25 |
34.925 |
50 |
M20*1.5 |
78 |
45 |
103 |
0.3 |
14 |
42.5 |
57 |
15 |
0.38 |
| SA22T/K |
20 |
22 |
28 |
38.1 |
54 |
M22*1.5 |
84 |
48 |
111 |
0.3 |
15 |
57 |
68 |
15 |
0.48 |
| SA25T/K |
22 |
25 |
31 |
42.85 |
60 |
M25*2 |
94 |
55 |
124 |
0.3 |
15 |
68 |
85 |
15 |
0.64 |
| SA28T/K |
25 |
28 |
35 |
47.6 |
66 |
M28*2 |
103 |
62 |
136 |
0.3 |
15 |
86 |
107 |
15 |
0.8 |
| SA30T/K |
25 |
30 |
37 |
50.8 |
70 |
M30*2 |
110 |
66 |
145 |
0.3 |
17 |
88 |
114 |
17 |
1.1 |
| SA35T/K |
28 |
35 |
43 |
57.1 |
81 |
M35*3 |
140 |
85 |
180.5 |
0.3 |
16 |
|
|
|
1.64 |
Application :
Engineering hydraulic cylinders,Forging machines,Construction machinery, Auto shock absorber etc
