12x35x15.9Mm Track Roller Bearings LR5201 KDDU LR5201KDDU LR 5201

Product Details

Place of Origin: China

Brand Name: SFT

Model Number: LR5201 KDDU

Payment & Shipping Terms

Minimum Order Quantity: negotiable

Price: negotiable

Packaging Details: carton,pallet

Delivery Time: 20-45DAYS

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 50000PCS/MONTH

Get Best Price
Highlight:

12x35x15.9Mm Track Roller Bearings

,

LR5201 KDDU Track Roller Bearings

,

LR5201KDDU Track Roller Bearings

ID:
12 Mm
OD:
35mm
Width:
15.9mm
Lubrication:
Oil, Greese
Number Of Row:
Single Row
Weight:
80g
ID:
12 Mm
OD:
35mm
Width:
15.9mm
Lubrication:
Oil, Greese
Number Of Row:
Single Row
Weight:
80g
12x35x15.9Mm Track Roller Bearings LR5201 KDDU LR5201KDDU LR 5201

Supply high quality track roller bearings LR5201 KDDU LR5201KDDU LR 5201 sizes 12x35x15.9 mm



Ball bearing track rollers are self-retaining, single or double row ball bearings with particularly thick-walled outer rings. In addition to high radial forces, these bearings can also support axial forces in both directions.



The outer rings have a crowned or cylindrical outside surface. Designs with a crowned outside surface are used where they are inclined in relation to the mating track and edge stresses must be avoided.



Ball bearing track rollers are available with an inner ring, with a stud and with a plastic tyre on the outer ring.

Yoke type track rollers with a crowned outside surface and stud type track rollers have a radius of curvature of R = 500 mm.



12x35x15.9Mm Track Roller Bearings LR5201 KDDU LR5201KDDU LR 5201 0








Type Weight D d B C R Rs Cw Cow Puw Seal Shield
(g) mm N
LR5200NPP 70 32 10 14 14 -- 0.6 6800 4050 168 8000 11000
LR5200NPPU 70 32 10 14 14 500 0.6 6800 4050 168 8000 11000
LR5200KDD 70 32 10 14 14 -- 0.6 6800 4050 168 8000 11000
LR5200KDDU 70 32 10 14 14 500 0.6 6800 4050 168 8000 11000
LR5201NPP 80 35 12 15.9 16 -- 0.6 8600 5100 211 7500 10000
LR5201NPPU 80 35 12 15.9 16 500 0.6 8600 5100 211 7500 10000
LR5201KDD 80 35 12 15.9 16 -- 0.6 8600 5100 211 7500 10000
LR5201KDDU 80 35 12 15.9 16 500 0.6 8600 5100 211 7500 10000
LR5202NPP 110 40 15 15.9 16 -- 0.6 9800 6200 258 7000 10000
LR5202NPPU 110 40 15 15.9 16 500 0.6 9800 6200 258 7000 10000
LR5202KDD 110 40 15 15.9 16 -- 0.6 9800 6200 258 7000 10000
LR5202KDDU 110 40 15 15.9 16 500 0.6 9800 6200 258 7000 10000
LR5203NPP 170 47 17 17.5 18 -- 0.6 12600 8200 342 5500 7500
LR5203NPPU 170 47 17 17.5 18 500 0.6 12600 8200 342 5500 7500
LR5203KDD 170 47 17 17.5 18 -- 0.6 12600 8200 342 5500 7500
LR5203KDDU 170 47 17 17.5 18 500 0.6 12600 8200 342 5500 7500
LR5204NPP 230 52 20 20.6 21 -- 1 15800 10500 433 5000 7000
LR5204NPPU 230 52 20 20.6 21 500 1 15800 10500 433 5000 7000
LR5204KDD 230 52 20 20.6 21 -- 1 15800 10500 433 5000 7000
LR5204KDDU 230 52 20 20.6 21 500 1 15800 10500 433 5000 7000
LR5205NPP 340 62 25 20.6 21 -- 1 18500 13000 532 4500 6500
LR5205NPPU 340 62 25 20.6 21 500 1 18500 13000 532 4500 6500
LR5205KDD 340 62 25 20.6 21 -- 1 18500 13000 532 4500 6500
LR5205KDDU 340 62 25 20.6 21 500 1 18500 13000 532 4500 6500
LR5206NPP 510 72 30 23.8 24 -- 1 24600 21400 880 3500 5000
LR5206NPPU 510 72 30 23.8 24 500 1 24600 21400 880 3500 5000
LR5206KDD 510 72 30 23.8 24 -- 1 24600 21400 880 3500 5000
LR5206KDDU 510 72 30 23.8 24 500 1 24600 21400 880 3500 5000
LR5207NPP 660 80 35 27 27 -- 1.1 30500 22400 927 2800 3900
LR5207NPPU 660 80 35 27 27 500 1.1 30500 22400 927 2800 3900
LR5207KDD 660 80 35 27 27 -- 1.1 30500 22400 927 2800 3900
LR5207KDDU 660 80 35 27 27 500 1.1 30500 22400 927 2800 3900
LR5208NPP 750 85 40 30.2 30 -- 1.1 34500 25500 1060 2500 3500
LR5208NPPU 750 85 40 30.2 30 500 1.1 34500 25500 1060 2500 3500
LR5208KDD 750 85 40 30.2 30 -- 1.1 34500 25500 1060 2500 3500
LR5208KDDU 750 85 40 30.2 30 500 1.1 34500 25500 1060 2500 3500
