Product Details
Place of Origin: China
Brand Name: SFT
Model Number: GE180-SW
Payment & Shipping Terms
Minimum Order Quantity: negotiable
Price: negotiable
Packaging Details: carton,pallet
Delivery Time: 20-45DAYS
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 50000PCS/MONTH
Outside Diameter: |
280 Mm |
Lubrication: |
Oil, Grease, Dry |
Material: |
Chrome Steel GCR15 |
Thickness: |
64 Mm |
Clearance: |
C2/C0/C3/C4 |
Feature: |
High Temperature Resistance .carrying Capability |
Outside Diameter: |
280 Mm |
Lubrication: |
Oil, Grease, Dry |
Material: |
Chrome Steel GCR15 |
Thickness: |
64 Mm |
Clearance: |
C2/C0/C3/C4 |
Feature: |
High Temperature Resistance .carrying Capability |
GE 180 SW Angular Contact Spherical Plain Bearing GE180-SW GE180 SW 280*64*180
Product Description of Spherical Plain Bearing:
Joint bearing is dominated by an inner and outer sphere within a spherical outer ring, can withstand
a greater load. According to their different types and structures that can withstand the
radial load, axial load or radial, axial joint load.
Since the inner surface of the outer sphere inlaid composite materials, so that the work
can be generated in the bearing selflubricating. Generally used for slower swing movement,
but also for the tilt angle within a certain range of motion, when the supporting shaft and shaft
misalignment large shell hole, still work properly. Selflubricating auxiliary bearing joints used in
water conservancy, specialized machinery and other industries.
GE180-SW The structure of the spherical plain bearing is mainly composed of an inner ring with outer sphere and an outer ring with inner sphere.The bearing is generally used for swinging motion of low speed. Due to the sliding surface of spherical shape, the bearing is used for tilted movement in certain Angle range ( the self-aligning movement),when the nonconcentricity between the supporting shaft and the shaft shell is bigger, the bearing can still work normally.
Drawing and Specification
| Type | d | D | B |
| GE25-SW | 25 | 47 | 15 |
| GE28-SW | 28 | 52 | 16 |
| GE30-SW | 30 | 55 | 17 |
| GE35-SW | 35 | 62 | 18 |
| GE40-SW | 40 | 68 | 19 |
| GE45-SW | 45 | 75 | 20 |
| GE50-SW | 50 | 80 | 20 |
| GE55-SW | 55 | 90 | 23 |
| GE60-SW | 60 | 95 | 23 |
| GE65-SW | 65 | 100 | 23 |
| GE70-SW | 70 | 110 | 25 |
| GE80-SW | 80 | 125 | 29 |
| GE90-SW | 90 | 140 | 32 |
| GE100-SW | 100 | 150 | 32 |
| GE110-SW | 110 | 170 | 38 |
| GE120-SW | 120 | 180 | 38 |
| GE130-SW | 130 | 200 | 45 |
| GE140-SW | 140 | 210 | 45 |
| GE150-SW | 150 | 225 | 48 |
| GE160-SW | 160 | 240 | 51 |
| GE170-SW | 170 | 260 | 57 |
| GE180-SW | 180 | 280 | 64 |
| GE190-SW | 190 | 290 | 64 |
| GE200-SW | 200 | 310 | 70 |
Advantages of sealed spherical plain bearings :
1.Can bear large load
2.Different types and structures
3.Self-lubricating
4.Used for low speed pendulum motion and low-speed rotation
5.Can do tilting motion in a certain angle range
6.Have bigger load capacity and impact resistant ability
7.Resist corrosion, resistant to wear , self aligning , good lubrication
8.Can work normally even installation dislocation
