Shaft Diameter 8mm Flange Mounted Linear Bearings LMF8UU LM8UU For CNC Machinery

Product Details

Place of Origin: China

Brand Name: SFT

Model Number: LMF8UU LM8UU

Payment & Shipping Terms

Minimum Order Quantity: negotiable

Price: negotiable

Packaging Details: carton,pallet

Delivery Time: 20-45DAYS

Payment Terms: L/C, T/T, Western Union, MoneyGram

Supply Ability: 50000PCS/MONTH

Get Best Price
Highlight:

8mm Flange Mounted Linear Bearings

,

LMF8UU Flange Mounted Linear Bearings

,

LM8UU Flange Mounted Linear Bearings

Material:
Chrome Steel/GCr15 Stainless Steel
Shaft Diameter:
8mm
Weight:
40g
Gear Type:
External Gear,internal Gear,without Gear
Type:
LINEAR, Linear
Hardness:
59-63 HRC
Material:
Chrome Steel/GCr15 Stainless Steel
Shaft Diameter:
8mm
Weight:
40g
Gear Type:
External Gear,internal Gear,without Gear
Type:
LINEAR, Linear
Hardness:
59-63 HRC
Shaft Diameter 8mm Flange Mounted Linear Bearings LMF8UU LM8UU For CNC Machinery

Top grade shaft diameter 8mm flanged linear motion bearings LMF8UU LM8UU for CNC machinery



Product details



1. Description of linear bearing:

Linear bearings and linear bearing and housing units are available in the compact, light, heavy duty, machined and plain bearing range. The bearings can support high loads while having a relatively low mass and allow the construction of linear guidance systems with unlimited travel
The range, which has been constructed and expanded in accordance with a modular concept, provides the best technical and economic solution, in relation to each application, for bearing arrangements with shaft guidance systems.



2.Drawing of linear bearing and technical data sheets:
Shield type: POM
Material incoming: 100% inspection
Hardness test: 100% pass
We can also supply following items:



Linear bearing is a kind of linear motion system, which is used to coordinate linear stroke with cylindrical shaft.Because the bearing ball contacts the point of bearing jacket, the steel ball rolls with the least friction resistance, so the linear bearing has small friction, and is relatively stable, does not change with the bearing speed, can obtain the stable linear movement with high sensitivity and precision.Linear bearing consumption also has its limitations, the most important is the bearing impact load capacity is poor, and the bearing capacity is poor, the second line bearing in high-speed movement of vibration and noise.Linear bearing automatic selection is included.Linear bearings are widely used in precision machine tools, textile machinery, food packaging machinery, printing machinery and other industrial machinery sliding parts.

Series LM..UU,LME..UU,LM..LUU,LME..LUU,LMF..UU,
LMF..LUU,LMK..UU,LMK..LUU,LMH..UU,LMEK..UU

3.Model selection of linear bearing:





Spec ID OD Lengh
LME5UU 5 12 22
LME8UU 8 16 25
LME12UU 12 22 32
LME16UU 16 26 36
LME20UU 20 32 45
LME25UU 25 40 58
LME30UU 30 47 68
LME40UU 40 62 80
LME50UU 50 75 100
LME60UU 60 90

125
