Product Overview:

The UD205 bearing is a high-quality, double-row spherical roller bearing unit designed for demanding applications. It combines superior performance with ease of installation, making it a popular choice across various industries.

Key Features and Benefits:

• Robust Construction: The UD205 features a sturdy cast iron housing that provides excellent protection against contamination and harsh operating conditions.

• Superior Load Capacity: Its double-row spherical roller bearing design enables it to handle heavy radial loads and moderate axial loads in both directions.

• Self-Aligning Capability: The spherical outer ring allows for slight misalignment between the shaft and housing, reducing stress and extending bearing life.

• Pre-Lubricated and Sealed: The UD205 comes pre-lubricated with high-quality grease and features effective seals to prevent lubricant leakage and contamination ingress, minimizing maintenance requirements.

• Easy Installation: The unit's compact design and standardized dimensions simplify installation and replacement, saving time and effort.

Applications:

The UD205 bearing is widely used in various industrial applications, including:

• Conveyors: Roller conveyors, belt conveyors, chain conveyors

• Material Handling: Pulleys, idlers, caster wheels

• Agriculture: Farm machinery, grain augers, hay balers

• Mining and Construction: Vibrating screens, crushers, feeders

•

Technical Specifications:

• Bore Diameter: 25 mm

• Outside Diameter: 52 mm

• Width: 34.1 mm

• Dynamic Load Rating: 22.4 kN

• Static Load Rating: 11.2 kN

• Limiting Speed: 6700 rpm

•

• Bearing No.	Dimensions! mm)					Basic load ratings ( KN )		Weight (kg)
  	d	D	B	S	r	Basic load ratings ( N )	Static Cor
  UD203	17	40	12	6.0	1.0	9.55	4.78	0.07
  UD204	20	47	14	7.0	1.5	12.82	6.65	0.12
  UD205	25	52	15	7.5	1.5	14.03	8.05	0.18
  UD206	30	62	16	8.0	1.5	19.47	11.43	0.26
  UD207	35	72	17	8.5	2.0	25.69	15.55	0.43
  UD208	40	80	18	9.0	2.0	29.51	18.14	0.60
  UD209	45	85	19	9.5	2.0	31.85	20.8	0.8
  UD210	50	90	20	10.0	2.0	34.99	23.7	0.83
  UD211	55	100	21	10.5	2.0	43.34	29.39	1.12
  UD212	60	110	22	11	2.0	47.68	33.43	1.55



Why Choose UD205?

• Reliability: Proven performance in demanding environments ensures long service life and reduced downtime.

• Versatility: Suitable for a wide range of applications across various industries.

• Cost-Effectiveness: Low maintenance requirements and extended service intervals contribute to lower operating costs.

Ordering Information:

The UD205 bearing is readily available from authorized distributors worldwide. Contact your local supplier for pricing and availability.

Conclusion:

The UD205 bearing is a reliable and versatile solution for your demanding applications. Its robust construction, superior load capacity, and ease of installation make it an excellent choice for ensuring smooth operation and maximizing productivity.
